WIFI20xx Serie

The major pain point on traditional meeting room is to connect all devices by cable, which is complex and wasting of time. CR-WIFI2000 Wireless conference system, start the meeting in anytime, anywhere, increase the efficiency on planning. Standard WiFi technology to co-work perfectly with existing networks. The CR-WIFI2000 wireless unit, choose the frequency point from dozens of available ones on our access point, working in zero interference with all other networks in the area.


  • Front panel USB recording interface
  • 3.5mm headphone for monitoring
  • 1x RCA audio input
  • 1x XLR audio input
  • 1x RCA audio output
  • 1x XLR audio output
  • 6x Phoenix interface audio output
  • 2x RJ45 digital audio connection
  • 3x RJ45 for chairman unit, delegate unit, unit translators and other connection
  • 1x RJ45 for wireless AP or router
  • 1x DP9 male interface for external control
  • 1x DP9 female interface for camera
  • 1x three-pin phoenix interface for camera control keyboard
  • 1x RJ45 for computer connection or network switcher
  • 1x grounding screw
  • 1x 100 ~ 240V DC Power Interface


Technical Parameters

  • Power 110V / 220V AC
  • Static power consumption 12W
  • Maximum power consumption 150W
  • Frequency Response 20Hz ~ 20KHz
  • Noise ratio (S / N)> 80dB
  • Total harmonic distortion <0.05%
  • Channel Crosstalk> 80dB
  • Dimensions (mm) 483L x 279W x43.6H
  • Dark gray color

Data sheet




Download (369.52k)
